(1) The battery pack is equipped with a BMS management system,
which is rich in functions and can realize convenient battery
management by cooperating with the upper computer software;
(2) The charging and discharging parameters need not be adjusted to
match the original switching power supply system in the machine.
(3) Compatible with multiple communication modes of R232, RS485 and
SNMP;
(4) A variety of installation and use modes are designed, which can
meet the requirements of diversified application scenarios,
such as standard cabinet, wall hanging, pole holding, landing,
strap, lever box, etc;
>Main Applications
● Video Devices:MP3/MP4/MP5,digital camera,portable DVD,portable
television,electronic cigarettes,electricity sound box,ect.
● Portable
Devices:GPS,PDA,E-book,PMP,PSP,laptop,walkie-talkies,portable
medical device,etc.
Illuminate Devices:Miner lamp,search light,ect.
● Others:Electric Toys,RC models,model aircraft,backup power,mobile
power supply,hand electric drill,ect.
>Model list
| Battery Model | LiFePO4 3.2V 6000mAh 32650/32700 |
| Nominal Voltage | 3.2V |
| Cell Diameter | 32.2±0.3mm |
| Cell Height | 70.5±0.3mm |
| Cell Weight | 140±5g |
| End of charge Voltage | CC Mode 3.65V |
| End of charge Current | CV Mode 0.3A |
| End of discharge Voltage | CC Mode 2.0V |
| Max Current | 5C |
| Charging Temperature | 0~60°C |
| Discharging Temperature | -20~60°C |
| Storage Temperature | -20~45°C |
>Our product Benefits:
1. High capacity
2. Excellent cycle life
3. Excellent high and low temperature performance
4. Steady output voltage
5. Low self-discharge
6. Double safety protection
7. With outstanding high level of vibrations and shocks
>Workshop scene
>Packing & Shipping
>Warning
To ensure proper use of the battery please read the manual
carefully before using it.
Handling
1. Do not expose to, dispose of the battery in fire.
2. Do not put the battery in a charger or equipment with wrong
terminals connected.
3. Avoid shorting the battery
4. Avoid excessive physical shock or vibration.
5. Do not disassemble or deform the battery.
6. Do not immerse in water
7. Do not use the battery mixed with other different make, type, or
model batteries.
8. Keep out of the reach of children.
Charge and discharge
1. Battery must be charged in appropriate charger only.
2. Never use a modified or damaged charger.
3. Do not leave battery in charger over 24 hours.
Storage
1. Store the battery in a cool, dry and well-ventilated area.
2. Disposal
Regulations vary for different countries. Dispose of in accordance
with local regulations.
>Cautions
1. Charging
Charging current:Cannot surpass the biggest charging current which
in this specification book stipulated.
Charging voltage:Does not have to surpass the highest amount which
in this specification book stipulated to decide the voltage.
Charge temperature:The battery must carry on the charge in the
ambient temperature scope which this specification
book stipulated
Uses the constant electric current and the constant voltage way
charge, the prohibition reverse
charges. If the battery positive electrode and the cathode meet
instead, can damage the battery.
2. Discharging current
The discharging current does not have to surpass this specification
book stipulation the biggest
discharging current, the oversized electric current electric
discharge can cause the battery capacity play to reduce and to
cause the battery heat.
3. Electric discharge temperature
The battery discharge must carry on in the ambient temperature
scope which this specification
book stipulated.
4. Over-discharges
After the short time excessively discharges charges immediately
cannot affect the use, but the long time excessively discharges can
cause the battery the performance, battery function losing. The
battery long-term has not used, has the possibility to be able to
be at because of its automatic flash over characteristic certain
excessively discharges the condition, for prevented excessively
discharges the occurrence, the battery should maintain the certain
electric quantity.
Company Profile
♦ we are specializing in researching.developing manufacturing and
marketing of Lithium-polymer battery, Cylindrical Li ion battery
and Li-Fepo4 battery, as well as concentrating on being a solution
provider for customized application of battery and power.
♦ We are a high-tech enterprise focusing on green energy and battery solutions, providing solutions for different device applications. Since it
foundation, PKnergy forces on service the area of Communication,
IT, home applications, financial,security, traffic, high end
consumer electronics, medical devices, electric tools and other
industry which involved battery & power.
♦ All products will be inspected in the testing system for 100% test.Our goal is to provides the best quality, complete battery models
and prompt service to every customer.After years of developing,
PKnergy because one of the top level Li-battery solution provider
in worldwide market.
