Rechargeable Sealed Lead Acid Battery Batteries Forklift 24v Lead Acid Battery

>Specification

Battery Size	65*198*405*435mm (single cell)
Weight	12.9kg
Product name	Lead-acid Traction Battery For Forklift
Type	Acid Lead Battery
Keyword	Forklift Battrey
Metal box's color	Black/Red/Yellow/Brown
Rated capacity	210AH
Number of poles	2 Terminals
Voltage	2V (singel cell)
Cycle life	1500 cycles at 80% DOD
Warranty	1 year
Certification	CE

>Main Features

1. Maintenance free sealed lead acid battery

As it is valve-regulated sealed lead acid battery.sealed and glass mat is used .acid is trapped inside. so refilling is not needed and is

leak proof.

2. No memory effect

Some Sealed Lead Acid batteries .say nickel –cadmium batteries will become conditioned to provide less power offer repetitious short

usage /discharge.

3. Low self discharge

The self –discharge rate for FOBERRIA Sealed Lead Acid Battery is about 2-3% per month at room .temperature compared with 20-30%

for other common battery systems.

4. Longer service life

Used thick and massive calcium grate ensure that FOBERRIA battery has a longer service life over 10years.

5. High discharge rate

Since the internal resistance is low .the battery can provide high rate of discharge.

6.Wide operation temperature range

VRLA Sealed Lead Acid Battery capacity is rated at 25°C, and will operate from 15°C +50°C when it is fly charged Ambient temperature

is 25°C.Service life will be more efficient under 15’C to 25”C .

>Structure and composition

Component	Positive plate	Negative plate	Container	Cover	Separator	Electrolyte	Safety valve	Terminal
Raw material	Lead dioxide	Lead	ABS	ABS	AGM	Sulfuric acid	Rubber	Copper

>Application

1. Solar power system(off-grid solar power system, solar street light system, solar garden light system);

2. Wind Power System;

3. UPS and computer backup power;

4. telecommunication system;

5. Power station System;

6. Railway System;

7. Emergency lighting system;

8. Automatic control system;

9. Alarm system for fire protection, security.

>Constant Current Discharge Characteristics(A,25ºC)

F.V/Time	10min	15min	30min	60min	2h	3h	4h	5h	8h	10h	20h
9.6V	71.9	55.4	33.2	20.4	12.1	8.58	6.93	5.92	4.07	3.36	1.78
9.9V	69.8	54.1	32.5	20.1	12	8.53	6.89	5.89	4.05	3.35	1.78
10.2V	66.9	52.1	31.5	19.6	11.9	8.47	6.85	5.85	4.02	3.34	1.77
10.5V	64	50.3	30.7	19.2	11.7	8.42	6.8	5.81	3.99	3.32	1.76
10.8V	60.4	47.7	29.6	18.6	11.4	8.16	6.59	5.63	3.87	3.3	1.75

>Constant Power Discharge Characteristics(Watt,25ºC)

F.V/Time	10min	15min	30min	60min	2h	3h	4h	5h	8h	10h	20h
9.60V	777	609	372	232	140	101	81.5	70	48.4	40.1	21.4
9.90V	754	594	365	229	139	100	81.1	69.6	48.1	40	21.3
10.2V	723	572	354	223	138	100	80.5	69.1	47.8	39.9	21.3
10.5V	691	553	345	219	136	99	79.9	68.7	47.4	39.7	21.1
10.8V	653	524	332	212	132	96	77.5	66.6	46	39.4	21

>Discharge diagram

>Charing
